Essential Product Info
Brand: Eaton
Manufacturer: Eaton Corporation
Model Number: BQ2302120
UPC Number: 786676371551
Type: Type BQ 1-Inch CTL Plug-On Circuit Breaker
Current Rating: (2) 20A Single-Pole, (1) 30A Two-Pole
Voltage Rating: 120/240V at 30A, 120V at 20A
Mounting Type: Plug-On
Number of Poles/Phases: 4-Pole
Short Circuit Current Rating (SCCR): 10 kAIC
Circuit Breaker Type: Thermal Magnetic
Protection Type: Overcurrent, Short Circuit
Compatibility: Type BR Load Centers
Electrical Connection: Plug-On Terminal
Wire Size Range: #14-4 AWG Cu/Al
Terminal Type: Plug-On
Dimensions (H × W × D): 3 × 2 × 3 inches
Weight: 0.7 lbs
Certifications: UL 489
Safety Compliance: HACR-Rated, Switch Duty-Rated
Key Features and Benefits
Reliable Protection – Ensures safe and efficient electrical operation with thermal magnetic trip technology.
High Interrupt Rating – 10 kAIC for superior short-circuit protection.
Plug-On Installation – Quick and secure panel installation for Type BR load centers.
Rejection Tab Feature – Prevents improper installation in non-compatible panels.
HACR & Switch Duty Rated – Suitable for HVAC systems and switch applications.
UL 489 Certified – Meets industry standards for safety and performance.
Applications
Residential Load Centers – Ideal for home electrical panels and power distribution.
Commercial Electrical Systems – Perfect for office buildings, retail spaces, and small businesses.
HVAC Systems – Suitable for heating, ventilation, and air conditioning equipment.
Switch Duty Applications – Designed for frequent switching operations.
Why Choose This Brand?
Eaton is a global leader in intelligent power management solutions, dedicated to improving safety, efficiency, and sustainability. The BQ2302120 circuit breaker combines advanced thermal magnetic technology with robust construction, ensuring reliable performance for residential and commercial applications.
Upgrade your electrical system with the Eaton BQ2302120 today!
