Eaton CHP24L125X2: 125 Amp Single-Phase Main Lug Loadcenter, 120/240V, 24 Spaces, 48 Circuits, NEMA 1 Indoor, Copper Bus, 25kAIC, UL Listed.
- Manufacturer: Eaton
- Brand: Eaton
- Product Range: CH (for Eaton CH circuit breakers)
- UPC: 786689054311
- Model Number: CHP24L125X2
- Product Type: Main Lug Loadcenter
- Amperage: 125 Amps
- Phase: Single-Phase
- Voltage: 120/240 Volts
- Interrupt Rating: 25 kAIC
- Number of Spaces: 24
- Number of Circuits: 48
- Bus Material: Copper
- Wire Size: #6-2/0 AWG Cu/Al
- Enclosure: NEMA 1 Indoor
- Enclosure Material: Steel
- Dimensions: Height: 21.0 in; Width: 14.3 in; Depth: 4.0 in
- Weight: 11.7 lbs
- Certifications: UL Listed
- Special Features: Plug-on Neutral (PON)
This Eaton CHP24L125X2 main lug loadcenter delivers reliable 125A, single-phase power distribution for 120/240V residential and light commercial applications. With 24 spaces and 48 circuits, it supports Eaton CH circuit breakers and features a plug-on neutral design for simplified installation. The copper bus and NEMA 1 indoor enclosure ensure durability and safety, with a 25kAIC interrupt rating for robust protection.
