Square D E-Frame EDB24015 15A 2P 480Y/277V 25kA Bolt-On Circuit Breaker
Regular price
$109.00 USD
Square D EDB24015: 15 Amp 2-Pole Thermal-Magnetic Circuit Breaker, 480Y/277 VAC, 25kA Interrupt Rating at 240V/480Y/277V, Bolt-On, Visi-Trip Indicator, UL Listed, HACR & HID Rated
- Manufacturer: Schneider Electric
- Brand: Square D
- Product Range: E-Frame (for Square D NF and NFM Panelboards)
- UPC: 785901879008
- Model Number: EDB24015
- Breaker Type: Thermal-Magnetic
- Amperage: 15 Amps
- Poles: 2-Pole
- Voltage: 480Y/277 Volts AC
- Interrupt Rating: 25 kA at 240 VAC, 18 kA at 480Y/277 VAC, 25 kA at 120/240 VAC
- Mounting Mode: Bolt-On
- Connections Terminals: Lugs (Aluminum/Copper)
- Wire Size: AWG 14...AWG 6 Copper, AWG 12...AWG 6 Aluminum
- Tightening Torque: 30.09 lbf.in
- Dimensions: Height: 5.66 in; Width: 1.96 in; Depth: 4.05 in
- Weight: 3.0 lbs
- Certifications: UL Listed, cULus, HACR Rated, HID Rated
- Local Signaling: Visi-Trip indicator (red trip flag)
This Square D E-Frame EDB24015 bolt-on circuit breaker delivers reliable 15A, 2-pole thermal-magnetic protection for 480Y/277V systems in NF panelboards. Featuring a 25kA interrupt rating at 240V, Visi-Trip indicator for faster troubleshooting, and robust overload/short-circuit performance, it is the ideal choice for commercial lighting panelboard applications requiring HACR and HID ratings.
